Alles, was Sie brauchen, um Ihre eigenen Bestandsaufnahmen selbst in 3D einzumessen und zu erfassen

Everything the Survey Package does, measuring and setting out to the centimetre, plus capturing the site in 3D. Scan an open trench with the cables and pipes in it, a facade or the surroundings as a full 3D model, and record your own as-builts on site instead of hiring a scanning service.

No. It is built for people without a surveying background. If you can use a smartphone and an iPad you can measure, set out and scan, and support walks you through the first setup.

The GNSS side is the same UNI-GR2: 8 mm + 1 ppm horizontal and 15 mm + 1 ppm vertical in the open field with an RTK fix, and 3 mm + 1 ppm static. Near buildings or trees expect closer to 2 cm. The LiDAR 3D capture sits on that same centimetre position.

Capture trenches, facades and surroundings as a full 3D point cloud with the iPad Pro LiDAR, and view and share it in UNI-Cloud. It is your own as-built of exactly what was there, before the trench closes.

You pick the coordinate reference system per project, with transformation grids on the iPad. RD and NAP in the Netherlands, OSGB36 in the UK, Lambert in Belgium, the national grid and height system in Germany, and any other system you need.

The same as the Survey Package: NLCS and NLCS++ for cables and pipes, CROW 500 and the DSP exchange in the Netherlands, and open protocols like NMEA-0183. It fits the delivery of this work too, from trial trenches (proefsleuven) to digital construction supervision (digitale Baubegleitung). If a standard you need is missing, we are open to it and think along with you.

One year of UNI-RTK Premium is included, with more than 2,000 base stations in over 30 countries. You can use your own NTRIP service such as SAPOS or FLEPOS instead, which are free, and save the € 1.000 a year, reflected in the package price.

€ 6.990 im ersten Jahr, danach € 2.095 a year for UNI-Cloud Ultimate and UNI-RTK Premium.

Ultimate adds the 3D LiDAR viewer, unlimited projects and layers, a public share link for your client, and a replacement receiver if yours fails. It is what lets you view and share the 3D captures.

Yes. Projects and layers sit on the iPad, so you keep measuring and scanning offline and everything syncs once coverage returns. You share a project, its map and the 3D model through a view link or QR code, so a client opens it without any software.

Yes. From UNI-Cloud the KLIC cable and pipe map loads as a layer over your project, in the field and in the office.

Yes. The same receiver and app survey and set out to the centimetre. If you never need 3D, the Survey Package covers that for less.

Yes. The UNI-GR2 is made for outdoor work in dust, rain and cold and runs a full day on one charge. The iPad rides in the case until you need it.

In den Niederlanden. Hardware und Software werden im eigenen Haus in Hilversum entwickelt, der UNI-GR2 wird in Rotterdam produziert. Europäische Bauqualität, ein Unternehmen hinter der gesamten Kette.

Unser eigenes Team in Hilversum geht von Montag bis Freitag von 09:00 bis 17:00 CET ans Telefon, unter lokalen Nummern in den Niederlanden, Deutschland und dem Vereinigten Königreich. Ab dem Professional-Abonnement übernehmen sie Ihr Gerät aus der Ferne, um Dinge direkt zu lösen.

Ja. Gerne zeigen wir Ihnen das System zunächst im Rahmen einer unverbindlichen Vorführung vor Ort: auf Ihrer Baustelle, in Ihrem Unternehmen oder in unseren Büroräumen. Bei der Lieferung gehen wir gemeinsam alles durch, damit Sie sofort loslegen können. Eine Schulung vor Ort ist auf Wunsch möglich, aber nicht zwingend erforderlich: Wenn Sie mit einem Smartphone umgehen können, können Sie auch damit arbeiten. Betrachten Sie es als zusätzliche Sicherheit, damit Sie das System optimal nutzen können. Und Sie können uns jederzeit anrufen.
